Description
Technical Specifications
| Parameter | Standard / Available Options |
|---|---|
| Tool Type | Solid Carbide Precision Tube Cutting Saw |
| Material | Ultra-Fine Grain Solid Carbide |
| Diameter | 150–200 mm typical / Custom |
| Thickness | 0.7–1.0 mm typical / Custom |
| Bore Size | 25.4, 32 mm typical / Custom |
| Tooth Count | 200T, 240T, 280T, 320T / Custom |
| Tooth Geometry | Application-specific / Custom |
| Edge Type | Toothed / Plain Edge |
| Kerf | Ultra-Thin / Custom |
| Carbide Grade | Application-specific |
| Coating | Uncoated / Custom |
| Mounting | Bore, keyways, drive holes & Custom |
| Marking | OEM Laser Marking / Private Label |
| Tolerance | According to drawing and application requirements |
Common Customer Specifications
The following are commonly manufactured configurations for precision tube cutting applications:
| Diameter (mm) | Thickness (mm) | Bore (mm) | Tooth / Edge |
|---|---|---|---|
| 150 | 0.7 | 25.4 | 200T |
| 160 | 0.8 | 32 | 240T |
| 160 | 0.7 | 32 | 280T |
| 160 | 1.0 | 32 | Plain Edge |
| 180 | 1.0 | 25.4 | 240T |
| 180 | 1.0 | 32 | 240T |
| 200 | 1.0 | 32 | 320T |
Other dimensions and tooth configurations are available according to customer requirements.
Typical Industries
- HVAC & refrigeration
- Medical & laboratory equipment
- Automotive
- Instrumentation & electronics
- Precision engineering
FAQ
What materials can these tube cutting saw blades cut?
They can be manufactured for copper, aluminum, stainless steel, precision steel and other tubing materials according to the application.
What tooth counts are available?
Common configurations include 200T, 240T, 280T and 320T. Custom tooth counts are available according to tube specifications and cutting conditions.
Can you manufacture custom tube cutting saw blades?
Yes. We manufacture custom diameters, thicknesses, bore sizes, tooth configurations, edge designs and other specifications according to drawings, samples or machine requirements.
Do you provide OEM manufacturing?
Yes. OEM laser marking and customized packaging can be provided for machine builders, tube manufacturers, distributors and cutting tool companies.
Request a Custom Precision Tube Cutting Saw
Send us your drawing, sample, tube specifications, machine information, or cutting requirements for a technical review and quotation.
